Power Film Resistors

• Resistance range 0.010 ohm up to 100K
• Heat sink mountable
• Up to 30 watts in TO-220 Style packages and 15 watts in TO-126 Style packages at 25°C case temperature
• Non-inductive design

• 50 watts in TO-220 Style package and 25 watts in TO-126 Style package at 25°C case temperature
• Resistance range 0.020 ohm up to 10K
• Non-inductive design
• Copper heat sink integral in molded package

• 100 watts continuous power at 25°C case temperature
• Resistance range of 0.050 ohm to 100 ohm
• Equivalent to UL94-V-O flammability rating
• Excellent pulse/surge performance
• Electrically isolated case
• Non-inductive design

• Resistance as low as 0.005 ohm at ±5%, 0.010 ohm at ±2%, and 0.020 ohm at ±1%
• Up to 60 amps at 25°C case temperature for 0.005 ohm up to 0.015 ohm
• Up to 60 watts at 25°C case temperature for 0.020 ohm and above
• Non-inductive design
• Heat sink mountable with clips

• 20 watts at 25°C case temperature derated to zero at +175°C
• Excellent high frequency performance
• Resistance to as low as 0.020 ohm at ±1%
• Non-inductive design

• Solderable thin gold lead finish
• 20 watts at 25°C case temperature derated to zero at +175°C
• Excellent high frequency performance
• Resistance range of 0.020 ohm to 10K at ±1%
• Non-inductive design

0.50 Watt and 0.75 Watt

• Non-inductive design
• Resistance range 1.00 ohm to 100 Meg
• TC as low as 50 ppm/°C, -15°C to 105°C
• Tolerance ±1% (available to ±0.1%)
• Space efficient radial-lead design

• Non-inductive design
• Power ratings from 0.25 watts to 22 watts
• Select from 18 models
• Voltage ratings from 200V to 6KV
• Resistance range 20 ohm to 30 Meg
• Tolerance of ±1% (available to 0.1%)
• Max. operating temperature of +275°C

• 25 watts at 25°C case temperature derated to zero at +150°C
• Metal tab assists in post-soldering inspection
• Non-inductive design

Resistance Range of 0.10 ohms to 50 ohms

• Power ratings from 1.5 watts to 10 watts
• Non-inductive design
• Select from 5 models
• Tolerance 1% (5% and 10% are also available)
• Max. operating temperature of +275°C
